Dettagli del prodotto
Luogo di origine: La CINA
Marca: LINK-PP
Certificazione: UL,RoHS,Reach,ISO
Numero di modello: E5J88-L4L3F2-L
Termini di trasporto & di pagamento
Quantità di ordine minimo: 50/500/1000/60K
Prezzo: $0.11-$24
Imballaggi particolari: VASSOIO
Tempi di consegna: Di riserva
Termini di pagamento: TT, giorni NET30/60/90
Capacità di alimentazione: 180K/Month
Spec.: |
E5J88-L4L3F2-L |
Porto: |
2x1 Rj45 femminile |
Ethernet: |
Ingresso/uscita di gigabit |
Famiglia: |
Jack integrato magnetico |
Montaggio: |
Entrata laterale (angolo retto) |
Spec.: |
E5J88-L4L3F2-L |
Porto: |
2x1 Rj45 femminile |
Ethernet: |
Ingresso/uscita di gigabit |
Famiglia: |
Jack integrato magnetico |
Montaggio: |
Entrata laterale (angolo retto) |
Part Status | Active | |
---|---|---|
Connector Type | Jack | |
Number of Positions/Contacts | 8p8c (RJ45, Ethernet) | |
Number of Ports | 2 | |
Number of Rows | 2 | |
Mounting Type | Through Hole | |
Orientation | 90° Angle (Right) | |
Termination | Solder | |
Shielding | Shielded, EMI Finger | |
Ratings | Cat3 | |
Features | Board Lock | |
LED Color | Yellow - Green | |
Ingress Protection | - | |
Tab Direction | Up and Down | |
Contact Material | Phosphor Bronze | |
Contact Finish | Gold | |
Contact Finish Thickness | 6.00µin (0.152µm) | |
Housing Material | Polyester, Glass Filled | |
Operating Temperature | 0°C ~ 70°C |
