Dettagli del prodotto
Luogo di origine: Guangdong, Huizhou
Marca: LINK-PP
Certificazione: SFP+ MSA, REACH, RoHS, FCC
Numero di modello: JNP-SFP-10G-BX60D
Documento: LS-BL332710-60C.pdf
Termini di trasporto & di pagamento
Quantità di ordine minimo: 1
Prezzo: $ 10
Imballaggi particolari: Schiuma + cartone
Tempi di consegna: 1-3 giorni
Termini di pagamento: T/T, L/C, CAD/D/P, OA
Capacità di alimentazione: 1300 in magazzino
Numero di parte: |
JNP-SFP-10G-BX60D |
Serie: |
Ricetrasmettitore BiDi SFP+ 10GBASE-BX-D |
Velocità dati: |
10.3125Gbps |
Lunghezza d'onda: |
TX da 1330 nm/RX da 1270 nm |
Consumo energetico: |
< 1,5 W |
Parte compatibile n.: |
LS-BL332710-60C |
Numero di parte: |
JNP-SFP-10G-BX60D |
Serie: |
Ricetrasmettitore BiDi SFP+ 10GBASE-BX-D |
Velocità dati: |
10.3125Gbps |
Lunghezza d'onda: |
TX da 1330 nm/RX da 1270 nm |
Consumo energetico: |
< 1,5 W |
Parte compatibile n.: |
LS-BL332710-60C |
The JNP-SFP-10G-BX60D is a high-performance 10GBASE-BX-D BiDi SFP+ transceiver designed for cost-effective long-reach 10G Ethernet connectivity.
It supports 10 Gbps data transmission over single-mode fiber (SMF) using a single LC simplex connector, enabling a maximum link distance of up to 60 km.
Operating on paired wavelengths 1330nm (TX) and 1270nm (RX), this BiDi module allows full-duplex communication over just one fiber strand, reducing fiber usage and lowering deployment costs.
The transceiver is fully compliant with SFP+ MSA, SFF-8431/8432/8472, and IEEE 802.3ae standards, ensuring seamless compatibility with a wide range of network equipment, including switches and routers.
The JNP-SFP-10G-BX60D is widely used in data centers, metro networks, enterprise distribution layers, and long-distance interconnect applications.
Specifications of JNP-SFP-10G-BX60D – 60km SFP+ BiDi Transceiver
| Parameter | Specification |
|---|---|
| Data Rate | 10.3125 Gbps (10G Ethernet) |
| Reach / Distance | Up to 60 km |
| Fiber Type | Single-Mode Fiber (SMF) |
| Connector | LC Simplex |
| Wavelength | TX 1330 nm / RX 1270 nm |
| Transmitter Type | DFB Laser |
| Receiver Type | APD Receiver |
| Optical Modulation | NRZ |
| DDM / DOM | Supported (per SFF-8472) |
| Parameter | Specification |
|---|---|
| Form Factor | SFP+ (Hot-Pluggable) |
| Supply Voltage | 3.3V |
| Power Consumption | < 1.5W |
| Protocols | 10GBASE-BX, 10G Ethernet, CPRI/OBSAI (where supported) |
| Compliance | SFF-8431, SFF-8432, SFF-8472, RoHS |
| Operating Temperature | 0°C to +70°C (Commercial) or –40°C to +85°C (Industrial version optional) |
This transceiver is designed for full compatibility with Juniper platforms and is suitable for use in devices such as:
